3-3.5 Ton Vertical Air Handler 120V AC Only
Part #UNIV3642B1EC1BX
MFG #V3642B-1EC1BX
Manufacturer Name : Unico
- Air Handler Unit
- Type Vertical
- Voltage Rating 120 Volt AC
- Current Rating 10.5 Amp
- Frequency Rating 50/60 Hertz
- Number of Phases 1
- Power Rating 10.5 Kilowatt
- Cooling Capacity 42000 BTU/Hour
- Temperature Control Type Thermostat
- Connection Type Screw Terminal
- Enclosure Material 22 Gauge Galvanized Steel
- Size 23.75 Inch Width x 25 Inch Depth x 44 Inch Height
- Weight 151 Pound
- Approval CE, ETL
- Cooling Coil Type 3 Row AC/Heat Pump
- Specification Sheet
- Balanced Wheel - All Blower Wheel are Individually Balanced. Direct Drive Motor. Adjustable Low Airflow Mode. Point-To-Point Wiring. Electric Heater Fan Interlock. Electric Heater Stage 3 Lockout. Chilled Water Relay. Humidifier Compatibility. Soft-Start and Soft-Stop. Constant Airflow. Low Airflow Indicator. Pre-Set Air Flow Rate. Optimized for Zoning with Hydronic Systems. Optimized for Efficiency and Sound.
