Part #HTPPH199119LP

MFG #PH199-119LP

Specifications

• Gas Fired Water Heater
• Type Condensing, Durable, High Performance
• Inlet/Outlet Connection 1-1/2 Inch Threaded x 1-1/2 Inch Threaded
• Gas Type Liquid Propane
• Gas Connection 3/4 Inch
• Relief Valve Details 3/4 Inch T and P Relief Valve Supplied
• Venting Type Direct
• Draft Hood Outlet/Vent Size 3 Inch
• Input Supply Rating 40000 to 199000 BTU/Hour
• Tank Dimensions 38-1/2 Inch Width x 74 Inch Height
• Tank Material High Grade 316L Stainless Steel
• Tank Capacity 119 Gallon
• Tank Warranty 7 Year Limited (Residential), 3 Year Limited (Commercial)
• GPH Recovery 230 GPH at 100 Deg F
• Ignition Type Spark
• Insulation Details 2 Inch Thick Foam
• Burner Type High-Grade Stainless Steel Inconel premix
• Energy Saver Conformance Yes
• Options Outdoor Sensor, PVC Concentric Vent Kit, Stainless Steel Outside Termination Vent Kit, Condensate Neutralizer, PC Connection Cable with Software, Sanitizer Booster Kit
• Inclusions/Features Intake PVC Tee with Screen, Exhaust PVC Coupling with Screen, Installation Manual
• Applicable Standard ETL (Canada and US), NSF, AHRI, UL/ULC, ASHRAE 90.1b, ANSI Z 21.10.3
• Lead-Free
• Auxiliary Connection Size 1 Inch Female Threaded
• Thermal Efficiency 96 Percent
• Temperature Rating 160 Deg F
