3003-33 Fernco Proflex 3" Copper X Copper/Plastic Shielded Coupling
Part #FER300333
MFG #3003-33
Fitting Size : 3"
Fitting Type : Coupling
Manufacturer Name : Fernco
Material : 301 Stainless Steel
- Proflex is a shielded transition pipe coupling that allows you to make pipe connections that are resistant to shear forces, while creating a rigid, long-lasting pipe joint. From 3/4" to 8" pipe diameters - Proflex connects cast iron, plastic, steel, copper and tubular, drain waste and vent systems for above-ground applications.
- Install Instructions
Specification Sheet - Gasket Material: Neoprene
- Gasket ID: Part No. and application on each gasket
- Shield assembly material requirements: All 300 series stainless steel Clamp
- Band = 301 stainless steel .025 x .500 x length
- Housing = 301 stainless steel - Fernco
- Screw = 305 stainless steel 5/16" Hex - No Slot
- Shield - 301 stainless steel .012 x 2.125 x length
- Eyelet - 305 stainless steel
- Installation Torque = 60" lbs
- Maximum test pressure: 4.3 PSI (29.6KPA)
- Maximum operating temperature: 180 Degree F
- Conforms to the requirement of ASTM C1460, ASTM C564 and CSA B602
