1-1/4" X 1-1/4" X 3/4" Cast Brass Monoflow Tee
Part #114.34CMT
MFG #302-207
End Connection : Sweat
Fitting Size : 1-1/4" X 1-1/4" X 3/4"
Fitting Type : Tee
Manufacturer Name : Legend
Material : Cast Brass
- Made of cast brass
- Monoflow Tees divert flow of water from main line to branch line and back again to main line
- Allows for a radiant system that does not require separate supply and return piping for each unit
- Install in proper location and orientation to ensure efficient operation of the heating system
- Not suitable for steam
- Max pressure and temperature may exceed that of PEX tubing
- Available in nominal sizes 3/4" X 1/2" - 1-1/4" X 3/4"
- Install Instructions
Specification Sheet - The cast brass Legend T-570 monoflow tee is designed to partially divert water flow from a primary hydronic loop into a secondary loop, through a radiation device, and then returned back to the primary loop. The differential pressure created by these tees creates the flow.
