TC20125ST Hayward TC Series 1-1/4" CPVC Socket/Threaded True Union Ball Check Valve with FPM O-Rings
Part #HAYTC20125ST
MFG #TC20125ST
End Connection : Socket Weld X Female Thread
Manufacturer Name : Hayward
Material : CPVC
Valve Size : 1-1/4"
- Available in PVC, CPVC and PP
- For Horizontal or Vertical Installation
- 1/2" to 6" are Sure Block Design
- Square Cut Seat for Positive Sealing
- Seats with Minimum Back Pressure
- 1/4" and 3/8" are Trim Check Design
- NSF / ANSI 61 and NSF / ANSI 372 Listed
- Install Instructions
Specification Sheet - TC Series true union ball check valves are offered in PVC, CPVC, and PP. O-rings and seats are FPM or EPDM. 1/4 in. and 3/8 in. sizes are PVC only and are trim check design. They have socket or threaded end connections. Others up to 2 in. sizes have socket and threaded end connections. All valves are assembled with silicone free lubricant.
