TI-8 3/8 FIPXFIP FULL PORT GATE VLV
Part #NIBTI838
MFG #N001165
End Connection : Female Thread
Manufacturer Name : Nibco
Material : Brass
Valve Size : 3/8"
- Gate Valve
- Type Solid Wedge, Full Port
- Actuation Type Handwheel
- Nominal Size 3/8"
- Stem Design Non-Rising
- End Connection Female Threaded x Female Threaded
- End to End Distance 1.61"
- Bonnet Type Threaded
- Body Material ASTM B584 C85700 Brass Alloy
- Stem Material ASTM B16 C36000 Brass Alloy
- Seal Material Non-Asbestos Graphite/Rubber
- Wedge Material ASTM B584 C85700 Brass Alloy
- Bonnet Material ASTM B584 C85700 Brass Alloy
- Handle Material ASTM A48 Cast Iron
- Pressure Rating 200 PSI Non-Shock CWP
- Inclusions/Features Screw-in-Bonnet, Steel Plated Nut, Brass Packing Nut/Gland/Lock Nut, Integral Seat
- Application Commercial, Residential, Irrigation
- Packaging Quantity 15 per Box
- Weight 0.55 Lb
- Warranty 2 Year Limited
- Specification Sheet
- The Nibco brass gate valve features a screw-in bonnet for a durable, pressure-tight seal. The non-rising stem gate valve with the cast iron handwheel offers positive shutoff. Threaded ends allow for ease of installation.
